240 Fuel Filter Location & Dieseling Problem

Experiencing Dieseling Problems?

B21F Engine – 240 Fuel Filter Location

Disconnect the battery negative lead making sure that you have the radio code if applicable. In the luggage compartment lift the carpet and you will see an inspection plate in the floor. Remove the plate to see the top of the sender unit. Disconnect the earth (ground) wire and the lead from the sender unit terminal. The sender unit is held in place by a locking ring which can be taken out with a special tool or by using a piece of hard plastic and a hammer. The plastic is to prevent sparks. Place it in one of the cut-outs in the ring and gently tap it until the ring comes loose. Lift the sender unit out of the tank. It is possible to make the tool if you want to.

The filter is on the very end of the unit. When replacing the sender you need a new gasket.

Dieseling Problem

Dieseling was a common problem on carb engines and can be caused by:

1. Incorrect timing. 2. A carburettor that does not close entirely can contribute to running once the engine is off, since the extra fuel and oxygen mixture can combust easily in the warm piston chamber. 3. An improperly rated spark plug can retain heat and cause the problem. 4. An engine that runs too hot or too lean may produce an environment conducive to allowing unspent fuel to combust. 5. An idle speed that is too fast can leave the engine with too much angular momentum upon shutdown, raising the chances that the engine can turnover and combust more fuel and lock itself into a cycle of continuous running. 6. Hot vaporized oil gases from the engine crankcase can provide ample fuel for dieseling. 7. Built-up carbon in the ignition chamber can glow red after the engine is switched off, providing a mechanism for sparking unburnt fuel. This can happen when the engine runs very rich, depositing unspent fuel and particles on the pistons and valves.

where is the fuel filter& why bogs out when I step on it?

Subscribe to the MVS Newsletter

The MVS Volvo Newsletter is a once-a-month email delivered to your email. It’s simple to unsubscribe at any time if you change your mind.

Visit The Official Volvo Cars Website

1 Comment

It sound so simple. Just “lift the sender unit out of the tank.” There are 2 hoses attached to it preventing removal. One hose leads to the fuel filter and inline pump. I got that one off. The other leads to a screw-in fitting on a metal tube. I keep pushing it off the pump nipple, but the nipple seems extraordinarily long! The local mechanic says I should cut the hose off, but then I can’t unscrew the other end to replace it. Do you have any tricks to either remove it from the sender unit nipple? Or to unscrew it at the other end without twisting and breaking the metal tube it is attached to?
