Search found 43 matches

by Azik09
Thu Jun 13, 2019 5:40 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: 98 S70 T5M: Diagnosing Cruise Control
Replies: 5
Views: 314
Russia

Re: 98 S70 T5M: Diagnosing Cruise Control

At first, check the electrical switches above brake and clutch pedals. I don't remember which contact of CC module they are connected to. CC module will not activate vacuum pump until it "see" pedals fully released.
by Azik09
Wed Jan 10, 2018 6:49 am
Forum: Volvo 440, 460, 480 Forum
Topic: OIL LEAKS
Replies: 3
Views: 1061
Russia

Re: OIL LEAKS

Where it leaks from? Gaskets, shaft seals or somewhere else?
by Azik09
Sat Dec 09, 2017 1:57 am
Forum: Volvo V70 & XC-70 2001-2007, S60 2001-2009
Topic: transmission from s40
Replies: 2
Views: 204
Russia

Re: transmission from S40

Can you give more information? VINs of both cars, photos of id. plates on gearboxes? If you don't know VIN from S40, so, at least, year and engine model.
by Azik09
Sat Dec 09, 2017 1:17 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Bad wires-total mess! Need help!
Replies: 6
Views: 511
Russia

Re: Bad wires-total mess! Need help!

You mean TCV wire? It's connected to engine control relay (grey, clamped above the radiator) and NOT protected by fuse. So, in case of a short, it will burn in seconds.
by Azik09
Thu Dec 07, 2017 11:29 pm
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Bad wires-total mess! Need help!
Replies: 6
Views: 511
Russia

Re: Bad wires-total mess! Need help!

Well, it is a little more serious damages, than just TCV wires... Why not to search the whole harness at junkyard? It's not difficult to replase it.
by Azik09
Thu Dec 07, 2017 6:32 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Bad wires-total mess! Need help!
Replies: 6
Views: 511
Russia

Re: Bad wires-total mess! Need help!

You need not to remove fuse or kick panels. One of two TCV wires (blue/brown) connected to crimped or soldered junction inside of engine wiring harness. It is the same wire that feeds injectors and idle air control valve (green). Second TCV wire (grey/black) connected directly to ECU, pin B41.
by Azik09
Thu May 11, 2017 8:08 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Same engine. different bosch mafs?
Replies: 16
Views: 1576
Russia

Re: Same engine. different bosch mafs?

MAF on my 1st photo is an insert from 0 280 217 107. I removed it from my own car (S70T5, 1997, M4.4) to make a photo, specially for you. :wink: I have not 0 280 217 002 right now, because I lent it to one of my clients. Maybe, later I'll make a photo. But they are REALLY different... 0 280 217 002 ...
by Azik09
Thu May 11, 2017 2:16 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Blew a valve - Before I sell S70 for parts
Replies: 10
Views: 836
Russia

Re: Blew a valve - Before I sell S70 for parts

hamhead wrote:
Wed May 10, 2017 12:41 pm
...and it'd be $3,700 to fix...
Wow!!! I would have done this job for $1000 with my pleasure. For $3,700 I can rebuild the whole engine, including cost of spare parts, dismantling and installing. But I'm too far, unfortunately.
by Azik09
Thu May 11, 2017 1:06 am
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Same engine. different bosch mafs?
Replies: 16
Views: 1576
Russia

Re: Same engine. different bosch mafs?

Perhaps, I was not quite accurate, English is not my native language. Inserts for Jetronic and Motronic are different! They have the same dimensions and connector, but their characteristic maps are completely different, so they are not interchangeable. You are right, 0 280 217 107 is a number of MAF...
by Azik09
Wed May 10, 2017 3:44 pm
Forum: Volvo 850, S70, V70, C70, XC models 1992-2000
Topic: Same engine. different bosch mafs?
Replies: 16
Views: 1576
Russia

Re: Same engine. different bosch mafs?

Bosch Maf sensor on '96 car have Bosch 0 280 217 107 part number....one and ONLY! It sells as a whole thing(with housing)from Bosch or Volvo. ;) '91-'95 cars have replaceable insert ONLY. ;) Bosch no.0 280 217 107 is saying everything about Maf for '96-'99 cars,it's like a fingerprint. However,i be...
