Issue * came across harvesting a MAf today
The MAf on NA cars are made by DENSO and mount with two M6 (10mm head ) bolts
The bolts are typical steel but bolt into brass threads fused into the air cleaner
I had bad galvanic corrosion on one of mine, so bad the fused and broke the threaded insert ou to the plastic
I had to Dremel it put and re-epoxy the insert into the MAF
Check your cat too, while you test your bolts.
P80 NA DENSO MAF mount bolts issue 1275636
-
abscate
- MVS Moderator
- Posts: 36137
- Joined: 17 Feb 2013, 17:54
- Year and Model: 99: V70s S70s,05 V70
- Location: Port Jefferson Long Island NY
- Has thanked: 1609 times
- Been thanked: 4063 times
- Attachments
-
-
-
-
-
Empty Nester
A Captain in a Sea of Estrogen
1999-V70-T5M56 2005-V70-M56 1999-S70 VW T4 XC90-in-Red
Link to Maintenance record thread
A Captain in a Sea of Estrogen
1999-V70-T5M56 2005-V70-M56 1999-S70 VW T4 XC90-in-Red
Link to Maintenance record thread
-
erikv11
- Posts: 11910
- Joined: 25 Jul 2009, 14:03
- Year and Model: 850, V70, S60R, XC70
- Location: Iowa
- Has thanked: 311 times
- Been thanked: 817 times
Denso is 99+ cars only. 98 and prior are Bosch, different part.
'95 854 T-5R, Motronic 4.4, 185k
'98 V70, T5 tune-injectors-turbo, LPT engine, 304k, daily driver
'06 S60 R, 201k
'07 XC70, black, 205k
'07 XC70, willow green, 223k
gone: '96 NA 850 210k, '98 NA V70 182k, '98 S70 NA 225k, '96 855 NA 169k
'98 V70, T5 tune-injectors-turbo, LPT engine, 304k, daily driver
'06 S60 R, 201k
'07 XC70, black, 205k
'07 XC70, willow green, 223k
gone: '96 NA 850 210k, '98 NA V70 182k, '98 S70 NA 225k, '96 855 NA 169k
-
wizechatmgr
- Posts: 1800
- Joined: 12 Jan 2017, 13:07
- Year and Model: 1999 V70 XC AWD 2.4T
- Location: Albany, NY area
- Has thanked: 45 times
- Been thanked: 128 times
- Contact:
Your cats appear to be bad, both are missing their precious metals =P
Wisdom requires knowledge as a prerequisite, but knowledge can be developed due to a lack of wisdom.
In order to learn how to fix something, you must first learn how to break it.
1999 V70 XC AWD 2.4 T -- ~231k miles
1998 V70 2.4 NA -- ~184k miles
In order to learn how to fix something, you must first learn how to break it.
1999 V70 XC AWD 2.4 T -- ~231k miles
1998 V70 2.4 NA -- ~184k miles
-
volvolugnut
- Posts: 6500
- Joined: 19 Jan 2014, 09:51
- Year and Model: 2001 V70
- Location: Oklahoma USA
- Has thanked: 987 times
- Been thanked: 1075 times
The cats also look dark - may need cleaning. Might be too rich condition.
(why you always want to logon and see the details and not just the text)
volvolugnut
(why you always want to logon and see the details and not just the text)
volvolugnut
The Fleet:
Volvo: 2001 V70 T5, 1986 244DL, 1983 245DL, 1975 245DL, 1959 PV544, multiple Volvo parts cars.
Mercedes: 2001 E320, 1973 280, 1974 280C, 1989 300E, 1988 300TE, 1979 300TD, parts cars.
2009 Smart Passion
Ford: 1977 F350, 1964 F150 (2), 1938 Tudor Sedan
Farmall tractors: 1956 400 Diesel, 1946 A
John Deere 214 lawn tractor about 1977 model
And others.
Volvo: 2001 V70 T5, 1986 244DL, 1983 245DL, 1975 245DL, 1959 PV544, multiple Volvo parts cars.
Mercedes: 2001 E320, 1973 280, 1974 280C, 1989 300E, 1988 300TE, 1979 300TD, parts cars.
2009 Smart Passion
Ford: 1977 F350, 1964 F150 (2), 1938 Tudor Sedan
Farmall tractors: 1956 400 Diesel, 1946 A
John Deere 214 lawn tractor about 1977 model
And others.
-
erikv11
- Posts: 11910
- Joined: 25 Jul 2009, 14:03
- Year and Model: 850, V70, S60R, XC70
- Location: Iowa
- Has thanked: 311 times
- Been thanked: 817 times
I see you got each cat to face the tail pipe, but now they flow in opposite directions???!!!
'95 854 T-5R, Motronic 4.4, 185k
'98 V70, T5 tune-injectors-turbo, LPT engine, 304k, daily driver
'06 S60 R, 201k
'07 XC70, black, 205k
'07 XC70, willow green, 223k
gone: '96 NA 850 210k, '98 NA V70 182k, '98 S70 NA 225k, '96 855 NA 169k
'98 V70, T5 tune-injectors-turbo, LPT engine, 304k, daily driver
'06 S60 R, 201k
'07 XC70, black, 205k
'07 XC70, willow green, 223k
gone: '96 NA 850 210k, '98 NA V70 182k, '98 S70 NA 225k, '96 855 NA 169k
-
abscate
- MVS Moderator
- Posts: 36137
- Joined: 17 Feb 2013, 17:54
- Year and Model: 99: V70s S70s,05 V70
- Location: Port Jefferson Long Island NY
- Has thanked: 1609 times
- Been thanked: 4063 times
Clarifying a bit more
The design is m6 bolt, clearance. Brass boss on air cleaner housing, threaded brass m6 insert in MAF, two pieces.
Look how the bolt corroded in the brass boss, but not in the insert.
Strange. When I went to unscrew this it locked up in both, then broke the insert out of the MAF. It was also locked into the brass boss.
The design is m6 bolt, clearance. Brass boss on air cleaner housing, threaded brass m6 insert in MAF, two pieces.
Look how the bolt corroded in the brass boss, but not in the insert.
Strange. When I went to unscrew this it locked up in both, then broke the insert out of the MAF. It was also locked into the brass boss.
