1999 V70 T5 M56 ELIZABETH 578465 Nautic Blue 417 Perfo 16 Wheels

Post by **abscate** » 15 Jul 2013, 11:13

Chassis 578465 10-98 build Ghent
Interior 3970
Color 417-26 Nautic Blue Metallic

VIN 578465
Engine number 1575162
Hyd lifters, 7.mm valve stems

Repair log in service as family car
Roughly 15000 miles per year

YV1LW53D5X2578465

Purchased 2000

Reset service light procedure

On the 1999

Ignition off.
Press in trip odometer reset button.
Switch on ignition.
Continue pressing in the reset button for 10 seconds. (Sing one third of the "Final Jeopardy" theme
Release reset button within 4 seconds.

Cut a piece of black electrical tape about 3/4" by 3/4" and place it over the light

Horrible advice, Shirley....

It's 19mm x19mm, and the electrical tape colour must match the body exterior, of course.

ETB Code 10W481302 - Dec 2010 build/software date - Mike posted software after 2006 is

Brake bleeder screw 30665014

Post by **abscate** » 15 Jul 2013, 11:14

CY 2009 Repairs and Records
Coil troubleshooting thread

https://www.matthewsvolvosite.com/forums ... il#p325109

Post by **abscate** » 15 Jul 2013, 11:19

CY 2013 Repair Records

Jan 19 143100 miles
R/R Front rotors
R/R front pads
Front right caliper tight
1mm bleed screw, 10 mm on replacements
M6 rotor retain screw hand tight
8mm hex caliper retaining pin
15mm Caliper bracket bolt - blue Loctite

Replaced Radiator - seep on passenger side
New coolant
https://www.matthewsvolvosite.com/forums ... t5#p275430

Feb 2013
Poor running due to induction hose leak, poor installation
New spark plugs 143000
https://www.matthewsvolvosite.com/forums ... =1&t=54781

Change oil/filter/air filter/ cabin air filter

Replace evap core and AC hardware lines, accumulator, expansion valve
Shim AC compressor
https://www.matthewsvolvosite.com/forums ... t5&start=0

Replace front calipers - RHS freezing up
https://www.matthewsvolvosite.com/forums ... t5#p289371

Replaced ignition switch electrical
https://www.matthewsvolvosite.com/forums ... t5#p281691

Root failure analysis on ignition switch 9447804
https://www.matthewsvolvosite.com/forum ... =1&t=80191

Replaced O2 sensors
https://www.matthewsvolvosite.com/forums ... t5#p284234

July 13 - replace coolant level sensor with new
https://www.matthewsvolvosite.com/forums ... el#p292579
p0327 and P0442 code, cleared, did not recur

Aug 22 2013
High speed trip (ALB to Wall Street via EWR round trip)
400 miles at 75mph average
ambient road temp 90-95
Used approx one half hash tag mark on dip stick
Computer reported 25.1 mpg

11 SEP 2013

CEL On, 149799 miles

P0442 Purge fault has been recurring
P0327 Knock sensor signal too low, shows up once in a while

Tested Purge Valve (later model) Resistance is 24.1 Ohms
Specification per AllData is Pulse ratio controlled valve. Resistance 29.7 ±1.4

Replaced Purge Valve, erased codes

Adjust parking brake
https://www.matthewsvolvosite.com/forums ... t5#p301094

Replaced MAP sensor on ETB
https://www.matthewsvolvosite.com/forums ... t5#p303447

Post by **abscate** » 19 May 2014, 04:26

2014 CY REPAIRs

Replaced sway bar link rods with OEM 158,200 miles
https://www.matthewsvolvosite.com/forums ... 63#p326663

Replaced blower motor
https://www.matthewsvolvosite.com/forums ... t5#p320751

Check coil resistances

https://www.matthewsvolvosite.com/forums ... il#p325109

6 JUNE 2014
New wiper blades front

Passed NYS inspection with evap code not ready (600+ miles) per EPA regs

29 June 2014
Repaired rear wiper, found broken wire in harness following left tailgate hinge, spliced with bullet connector. Followed good thread here

https://www.matthewsvolvosite.com/forums ... 3&start=14

Road trip. 70 mph ALB NYC reported 27 mpg.

More links on tailgate repairs

https://www.matthewsvolvosite.com/forums ... =9&t=47882

22 SEP 2014
Replaced springs, shocks, delta links, trailing arm bushings rear.
IPD HD springs
Gained 1-2 inches rear ride height

Replaced springs, struts, all mounts, front
Replaced growler Front left wheel bearing with FAG
Installed IPD strut brace

Destroyed CV joint cage, inner doing job
Installed used left axle from Erie Volvo
https://www.matthewsvolvosite.com/forums ... t5#p340662

replaced Manual transmission oil with Valvoline Synthetic - no residue on magnetic plug
Oil filter change with Mobil 1 synthetic

viewtopic.php?f=1&t=66079&p=520136#p520136

Repaired left rear ABS harness
https://www.matthewsvolvosite.com/forums ... t5#p352625

Miles 159XXX

Post by **abscate** » 10 Jul 2015, 19:33

CY 2015 REPAIRS

29 June 2015
Occasional P1332 CVVT solenoid code pops up, removed solenoid and cleaned in carb cleaner

Codes coming up less often, approximately 1500 mile intervals
Code does not pend.

6 July 2015
Major PCV service at 167314 mile

Followingprocedurehere

viewtopic.php?f=1&t=55413&hilit=Pcv

https://www.matthewsvolvosite.com/forums ... =1&t=55413

Thread on MEASURED SPARK PLUG GAP WEAR P80

viewtopic.php?f=1&t=70791&hilit=spark+plug+wear

167500 miles
Oil change Mobil synthetic 0-40
Oil filter change
Coolant change
New thermostat 87 C
Cabin filter change

Replaced turbo coolant inlet and outlet hoses
Replaced heater hoses
Installed 16 psi boost control valve
PCV hose, PTC valve, induction hose
New oil separator box and hoses
Checked turbo...no axial or radial play
All induction no visible oil
ETM inspected but did not require cleaning

Notes on servicing compressor boost valve here
https://www.matthewsvolvosite.com/forums ... =1&t=70733

14 July 2015
PCV manifold replacement documented here

https://www.matthewsvolvosite.com/forums ... 43#p372143

Replaced oil cooler lines, documented here

https://www.matthewsvolvosite.com/forums ... =1&t=70813

New clutch, brake, and footrest pads.

Also documented 1999 ME7 vacuum hose routing here
https://www.matthewsvolvosite.com/forums ... se#p372120

Link to PDFs on ME7 Evap testing protocol

https://www.volvoclub.org.uk/tech/fuel_ ... 0-RFLS.pdf

21 AUG 2015

Alternator bearing service, also serpentine belt route picture, 167750 miles

https://www.matthewsvolvosite.com/forums ... =1&t=71481

Bookmarking thread on this
https://www.matthewsvolvosite.com/forums ... hp?t=63879

Adjusted turbo wastegate actuator with thread

https://www.matthewsvolvosite.com/forums ... =1&t=71734

18 OCTOBER 2015
Oct 17 2015 170100 miles
R/R right front wheel bearing

Lug nuts
6mm hex key
14mm brake caliper bolts
Ball joint nut/bolt
Tie rod end
Carrier bearing bolts, 12mm
Drift, hammer
String to tie up caliper

Thread here
Stub axle stuck in knuckle
FWB screw caps were different size
TSB on plastic shield for FWB
Procedure for removal of passenger drive shaft, MT 1999

https://www.matthewsvolvosite.com/forums ... =1&t=72502

Thread for ME7 Cruise control troubleshooting

https://www.matthewsvolvosite.com/forums ... 43#p384543

Link rto thread on repairing pax side ABS sensor

https://www.matthewsvolvosite.com/forums ... 40#p385440

Post by **abscate** » 14 Jul 2015, 16:12

PCV manifold replacement documented here

https://www.matthewsvolvosite.com/forums ... 43#p372143

Replaced oil cooler lines, documented here

https://www.matthewsvolvosite.com/forums ... =1&t=70813

New clutch, brake, and footrest pads.

Also documented 1999 ME7 vacuum hose routing here
https://www.matthewsvolvosite.com/forums ... se#p372120

Link to PDFs on ME7 Evap testing protocol

https://www.volvoclub.org.uk/tech/fuel_ ... 0-RFLS.pdf

Post by **abscate** » 21 Aug 2015, 08:03

Alternator bearing service, also serpentine belt route picture, 167750 miles

https://www.matthewsvolvosite.com/forums ... =1&t=71481

Bookmarking thread on this
https://www.matthewsvolvosite.com/forums ... hp?t=63879

Adjusted turbo wastegate actuator with thread

https://www.matthewsvolvosite.com/forums ... =1&t=71734

Post by **abscate** » 18 Oct 2015, 10:26

Oct 17 2015 170100 miles
R/R right front wheel bearing

Lug nuts
6mm hex key
14mm brake caliper bolts
Ball joint nut/bolt
Tie rod end
Carrier bearing bolts, 12mm
Drift, hammer
String to tie up caliper

Thread here
Stub axle stuck in knuckle
FWB screw caps were different size
TSB on plastic shield for FWB
Procedure for removal of passenger drive shaft, MT 1999

https://www.matthewsvolvosite.com/forums ... =1&t=72502

Thread for ME7 Cruise control troubleshooting

https://www.matthewsvolvosite.com/forums ... 43#p384543

Link rto thread on repairing pax side ABS sensor

https://www.matthewsvolvosite.com/forums ... 40#p385440

Post by **abscate** » 25 Jan 2016, 04:50

2016 log

Added 1 at oil at 174100 miles. Usage approx 1 qt per 2500 miles
Topped off with 200 ml coolant
Exhaust hub still growling the same

FEB 2016
NO start debacle in Oneonta NY
https://www.matthewsvolvosite.com/forums ... a&start=10

1 APRIL 2016
Oil change at 174900

Replaced clutch switch at 175485 - failure logged in DTC, cruise control INOP

Rear defogger INOP - checked, replaced number 14 fuse, 30 Amp - probably blew during no-start debacle above, due to short in rear tailgate loom

Post by **abscate** » 09 May 2016, 07:43

May 2016
177800

Rear brake rotors, pads, RR
Adjust parking brake

viewtopic.php?f=1&t=75457&p=480417#p480417

Add 1/2 liter oil at 178000

Soldered in wire repair to left rear ABS sensor, wire loomed. 178600 reset ABS light to clear fault
