Volvo transmissions vary by model and year, so here’s a guide to help identify which transmission your Volvo has.
Volvo Automatic Transmissions 1980s – 2000s
| Model | Year | Engine Size | Trans Type | Transmission Model |
| 240 | 1985-1992 | AW70 | ||
| 240 | 1992-93 | Inline 4 2.3L | 4 Spd RWD | A42DL (03-70L) |
| 260 | 1980-1982 | BW55 | ||
| 740 | 1985-1994 | AW70L | ||
| 740 | 1990-1994 | AW72L | ||
| 740 | 1990-92 | Inline 4 2.3L | 4 Spd RWD | A42DL (03-70L) |
| 740 | 1990-92 | Inline 4 2.3L (W/Turbo) | 4 Spd RWD | A43DL (03-71) |
| 740 | 1990-92 | Inline 4 2.3L | 4 Spd RWD | A44DL (03-72L) |
| 850 | 1993-97 | Inline 5 2.3L 2.4L | 4 Spd FWD | 50-40 (AW50-40) |
| 940 | 1991-1994 | AW71L | ||
| 940 | 1992-95 | Inline 4 2.3L (W/Turbo) | 4 Spd RWD | A43DL (03-71) |
| 960 | 1992-1994 | AW40(A340E) | ||
| 960 | 1992-97 | Inline 6 2.9L | 4 Spd RWD | A341E (30-40LE) |
| 120, 140, 160, 240, 1800 | 1964-1975 | BW35 | ||
| 240, 260 | 1974-1983 | BW55 | ||
| 740 Diesel | 8/1984-1988 | ZF4HP22 | ||
| 740 Turbo | 1985-1994 | AW71,L | ||
| 740, 760, 780 | 1986-1988 | ZF4HP22 | ||
| 740, 780 | 1984-1991 | AW70 | ||
| 760 Turbo Diesel | E1983-1984 | BW55 | ||
| 760, 780 | 1985-1990 | AW71 | ||
| C70 | 1998-00 | Inline 5 2.3L 2.4L | 4 Spd FWD | AW50-42LE |
| C70 | 2001-04 | Inline 5 2.3L 2.4L | 5 Spd FWD | AW55-50SN |
| Cross Country | 2002 | Inline 5 2.4L | 5 Spd AWD | AW55-50 |
| S40 | 2000 | Inline 4 1.9L | 4 Spd FWD | AW50-42LE |
| S40 | 2001-04 | Inline 4 1.9L | 5 Spd FWD | AW55-50SN |
| S40 | 2005-06 | Inline 5, 2.5L | 5 Spd AWD | AW55-50 |
| S40 | 2005-06 | Inline 5 2.4L 2.5L | 5 Spd FWD | AW55-51 |
| S60 | 2001 | Inline 5 2.3L 2.4L | 5 Spd FWD | AW55-50SN |
| S60 | 2003-06 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| S60 | 2003-06 | Inline 5 2.4L 2.5L | 5 Spd FWD | AW55-50SN |
| S60 R | 2006 | Inline 5 2.5L | 6 Spd AWD | TBD |
| S70 | 2000 | Inline 5 2.4L | 5 Spd AWD | AW55-50 |
| S70 | 2000 | Inline 5 2.4L | 5 Spd FWD | AW55-50SN |
| S70 | 1998-00 | Inline 5 2.3L 2.4L | 4 Spd FWD | AW50-42LE |
| S80 | 1999-04 | Inline 5 2.4L 2.5L | 4 Spd FWD | AW50-42LE |
| S80 | 2004-06 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| S80 | 2004-06 | Inline 5 2.5L | 5 Spd FWD | AW55-50SN |
| S90 | 1997-98 | Inline 6 2.9L | 4 Spd RWD | A341E (30-40LE) |
| V40 | 2000 | Inline 4 1.9L | 4 Spd FWD | AW50-42LE |
| V40 | 2001-04 | Inline 4 1.9L | 5 Spd FWD | AW55-50SN |
| V50 | 2005-06 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| V50 | 2005-06 | Inline 5 2.4L 2.5L | 5 Spd FWD | AW55-50SN |
| V70 | 1998-00 | Inline 5 2.3L 2.4L | 4 Spd FWD | AW50-42LE |
| V70 | 1998-00 | Inline 5 2.3L 2.4L 2.5L | 4 Spd AWD | AW50-42LE |
| V70 | 2000-05 | Inline 5 2.3L 2.4L 2.5L | 5 Spd AWD | AW55-50 |
| V70 R | 2000 | Inline 5 2.4L | 5 Spd FWD | AW55-50SN |
| V70 | 2000-06 | Inline 5 2.3L 2.4L 2.5L | 5 Spd FWD | AW55-50SN |
| V70 R | 2004 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| V70 R | 2005-2007 | Inline 5 2.5L | 6 Spd AWD | TF-80SC |
| V90 | 1997-98 | Inline 6 2.9L | 4 Spd RWD | A341E (30-40LE) |
| XC70 | 2003-06 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| XC90 | 2006 | V8 4.4L | 6 Spd AWD | AWTF80SC |
| XC90 | 2003-05 | Inline 6 2.9L | 4 Spd AWD | A341E (30-40LE) |
| XC90 | 2003-06 | Inline 5 2.5L | 5 Spd AWD | AW55-50 |
| XC90 | 2003-06 | Inline 5 2.5L | 5 Spd FWD | AW55-50SN |
