850 Fuel Pump Relay Capacitor

Let’s talk about this Fuel Pump Relay Capacitor

jreed wrote:

“Thanks. I pulled the relay today (Volvo part # 89 8797 000) and took a look. I found that the capacitors were 22uF and 100uF just as on the 89 8769 000 part number that you repaired. One additional thing is that on the side of the 22uF, the temperature is rated 105C, which is a higher temp than the standard 85C for aluminum electrolytics. It’s probably a good idea to replace the capacitors with higher temperature rated parts, such as the Panasonic P13132-ND (22uF, 50V) and P13122-ND (100uF, 25V) from DigiKey (37 cents and 44 cents each + $2.41 shipping) which are rated for 7000 hrs at 105C (the maximum I could find). These parts are approximately the same dimensions as the original caps (original 22uF, 25V cap is 5mm dia x 12mm tall, with 2.5mm lead spacing; the original 100uF, 16V cap is 5mm dia x 12mm tall with 3mm lead spacing). The DigiKey 22uF is 5mm x 15mm and has 2mm lead spacing and the 100uF is 6.3mm x 15mm with 2.5mm lead spacing. I’m going to buy these parts and install them next weekend I hope and will post a report.
I also took a look at the solder joints for the relay. There are many of them and all of them except two at the base showed cracking in the solder joints. I took a picture of two of the cracked joints (attached). I reflowed the joints and added a little fresh solder to fix.



It’s probably a good idea to replace the capacitors with higher temperature rated parts, such as the Panasonic P13132-ND (22uF, 50V) and P13122-ND (100uF, 25V) from DigiKey (37 cents and 44 cents each + $2.41 shipping) which are rated for 7000 hrs at 105C (the maximum I could find). These parts are approximately the same dimensions as the original caps (original 22uF, 25V cap is 5mm dia x 12mm tall, with 2.5mm lead spacing; the original 100uF, 16V cap is 5mm dia x 12mm tall with 3mm lead spacing). The DigiKey 22uF is 5mm x 15mm and has 2mm lead spacing and the 100uF is 6.3mm x 15mm with 2.5mm lead spacing.

Fuel Pump Relay capacitor value question

Welcome to Matthews Volvo Site! Your one stop shop for all Volvo news, help and DIY fixes. We feature the Volvo Repair Database, the best Volvo Forum, and an awesome monthly Volvo newsletter. Joining is always free!

Subscribe to the MVS Newsletter

The MVS Volvo Newsletter is a once-a-month email delivered to your email. It’s simple to unsubscribe at any time if you change your mind.

Visit The Official Volvo Cars Website

2 Comments

De Strickland says:

My car has problems starting in cold weather, and now in warmer weather, it starts and cuts off in a few seconds. Have replaced fuel pump and fuel filter, and checked battery. Any suggestions? Need help ASAP.
Thanks.

Bill Burke says:

I was having cold start problems on my 850 and took your advise on changing out the faulty capacitors and Viola!Saved me time and mucho dinero.

Thank you

Great site!!!
